Power supply:

18 V DC

Total connected load:

45W

Protection:

IP20

Bus bar:

Power supply via barrel plug (M) Built-in version Power connection cable with plug-in power supply (supplied)

LED Type:

1 x 45 W high-power 15in1 TCL  R：5*3W  G：5*3W  B：5*3W

DMX Channels:

4

DMX Input:

1 x 3-pin XLR (M) built-in version

DMX Output:

1 x 3-pin XLR (W) built-in version

Cooling:

Fan

Control:

Stand-alone; DMX; Music control via microphone

Pre-programmed for:

LED PC-Control 512

Plug Type:

3-pin XLR (W); 3-pin XLR (W)

Port Connector Size:

＆#216; 25mm  ＆#216; 0.75mm * 1100 Pieces

Housing color:

Silver-grey

Diameter mounting holes:

4 x ＆#216;4mm

Material:

Metal, 1 mm

Weight:

2300 g

Noise classification:

Class 0 (no noise at all); class 2 (light noises)

Photobiological safety:

Risk group 0

Device

Metrics:

Width: 235 mm
Depth: 128 mm
Height: 98 mm

External power supply

Power supply:

100-240 V AC, 50/60 Hz

Pinout:

Inside + / Outside -

Cable length:

Approx. 1.5 m

Exit:

18 V DC; 2.5 A;

Color:

Black

XLR Cable

Cable length:

Approx. 1.2 m

Plug Type:

3-pin XLR (W); 3-pin XLR (M)

Color:

Black

PACK

EAN

Weight

Dimension

1

  2.3kg

     270mm x 135mm x115mm
