Power supply:

5 V DC

Total connected load:

12 W

Protection:

IP20

Bus bar:

Power supply via barrel plug (M) Built-in version Power connection cable with plug-in power supply (supplied)

LED Type:

1 x 9 W high-power 3in1 TCL RGB

DMX Channels:

4

DMX Input:

1 x 3-pin XLR (M) built-in version

DMX Output:

1 x 3-pin XLR (W) built-in version

Cooling:

Fan

Control:

Stand-alone; DMX; Music control via microphone

Pre-programmed for:

LED PC-Control 512

Plug Type:

3-pin XLR (W); 3-pin XLR (W)

Fiberglass strands:

＆#216;0.75mm x 450 Pieces

Housing color:

Silver-grey

Diameter mounting holes:

4 x ＆#216;4mm

Material:

Metal, 1 mm

Weight:

990 g

Noise classification:

Class 0 (no noise at all); class 2 (light noises)

Photobiological safety:

Risk group 0

Device

Metrics:

Width: 19.5 cm
Depth: 8.5 cm
Height: 5 cm

External power supply

Power supply:

100-240 V AC, 50/60 Hz

Pinout:

Inside + / Outside -

Cable length:

Approx. 1.5 m

Exit:

5 V DC; 2.5 A;

Color:

Black

XLR Cable

Cable length:

Approx. 1.2 m

Plug Type:

3-pin XLR (W); 3-pin XLR (M)

Color:

Black

Legal Specifications

Use:

Lighting for show effects

PACK

EAN

Weight

Dimension

1

1.10 kg

25cm x 29cm x 5cm
